The Art Of Touch · Displax Skin Ultra Fit

What the ancients called a clever fighter is one who not only wins, but excels in winning with ease. ~ Sun Tzu
Displax Skin Ultra Fit · 40 simultaneous touch points · multitouch skin
Displax Skin Ultra Fit · 5 millisecond response · multitouch skin
Displax Skin Ultra Fit · 20 to 105 inch diagonal · multitouch skin
Displax Skin Ultra Fit · 40 simultaneous touch points · multitouch skin
Displax Skin Ultra Fit · 40 simultaneous touch points · 5 millisecond response
Displax Skin Ultra Fit · 20 to 105 inch diagonal · multitouch skin
Displax Skin Ultra Fit · 40 simultaneous touch points · multitouch skin
Displax Skin Ultra Fit · 5 millisecond response · multitouch skin
Displax Skin Ultra Fit · 20 to 105 inch diagonal · multitouch skin

The best of the Skin Ultra meets the best of the Skin Multitouch.

Proving that you really can be all things to all people, as long as you show up early, work hard all day and go home late.
Nobody said success was going to be easy.

Quick

As in 5 milliseconds quick. That's 145 milliseconds faster than shifting from first to second in an Enzo Ferrari.

Accurate

Your software should recognize the same touch point your finger does. Ultra Fit is accurate to 1 millimeter absolute.

Substrate

Up to 15 millimeter float glass, but closer to 6 is better and 2 to 4 millimeter Gorilla Glass is best. No acrylics.

HID

Your IT guy will appreciate that the Ultra has done away with manual installation of drivers.

Big

First select standard or widescreen format and then from 23 sizes starting at 20" and up to 105" diagonal.

OS

Ultra Fit loves Windows, Ubuntu, Linux, Android and Chrome. It gets along with OS X but only one touch at a time.

Noise

Displax XTR-Shield™ sets the Ultra Fit far above lesser touch products and much closer to the LCD.

Parallax

Ultra Fit is set just a few millimeters above new low-noise displays which all but eliminates any parallax effect.

Hot

Ultra Fit performs at -20° and +70° and up to 96% humidity. Although most of your users probably won't.





Specifications · Displax Skin Ultra Fit

Now the general who wins a battle makes many calculations in his temple ere the battle is fought.
The general who loses a battle makes but few calculations beforehand. ~ Sun Tzu
Parameters Ultra Ultra Fit Dualtouch Sense

Specifications Download Displax Skin Ultra Specifications Download Displax Skin Ultra Fit Specifications Download Displax Skin Dualtouch Specifications
User guide Download Displax Skin Ultra User Guide Download Displax Skin Ultra Fit User Guide Download Displax Skin Dualtouch User Guide
Standard drawings Download Displax Skin Ultra Standard Drawings Download Displax Skin Ultra Fit Standard Drawings Download Displax Skin Dualtouch Standard Drawings
Application note Download Displax Skin Ultra Application Note Download Displax Skin Dualtouch Application Note
Quick start guide Download Displax Skin Dualtouch Quick Start Guide
Adhesive applications Download Displax Skin Dualtouch Adhesive Applications

Touch points · simultaneous 100 40 2 100
Sizes · inches diagonal 30 ~ 105 20 ~ 105 20 ~ 100 55
Sensor thickness · µ 125 125 100
Sensor weight · grams 260 260 200
Controller weight · grams 60 42 65
Interface HID HID driver HID

Viewing

Transparency · % 96 96 96 96
Monitor · LED/LCD yes yes yes yes
Rear projection screen yes yes yes yes

Performance

Noise shielding · XTR-Shield Plus yes yes yes
Noise shielding · XTR-Shield yes
Pressure sensing · XTR-Pressure yes yes yes yes
Touch response · ms 5 5 18 9
Touch response · fps 200 200 50
Touch accuracy absolute · mm 1 1 1
Touch accuracy relative · mm 1
Maximum substrate thickness · mm 6 15 20 6

Power

Input power maximum · mA 410 450 410
Input power rated · mA 370 310 370
Input voltage · USB 5V 5V 5V 5V

Operating

Operating temperature · °C -20 ~ 70 -20 ~ 70 -20 ~ 70 -20 ~ 70
Lifetime · hours 1000000 1000000 1000000 1000000

Installation

Permanent adhesive to glass yes yes yes
Static cling to glass · optional yes yes yes
Glass · factory applied yes
Method We advise the use of a professional to apply Displax to local glass substrates

Fine Print

Warranty Faulty components to be repaired or exchanged for 1 years from the date of shipping: details
Specifications Displax reserves the right to change any technical specifications without prior notice.


Displax Skin Ultra Fit · installation · fourty touch sensor for application to glass
Displax Skin Ultra Fit · installation · fourty touch sensor for application to glass
Displax Skin Ultra Fit · installation · fourty touch sensor for application to glass
Displax Skin Ultra Fit · installation · fourty touch sensor for application to glass
Displax Skin Ultra Fit · installation · fourty touch sensor for application to glass


Pricing · Displax Skin Fit

Ponder and deliberate before you make a move. ~ Sun Tzu
Ultra
20''$call
22''$call
23''$call
24''$call
26''$call
30''$call
32''$call
40''$call
42''$call
43''$call
46''$call
47''$call
48''$call
49''$call
50''$call
52''$call
55''$call
57''$call
58''$call
60''$call
65''$call
68''$call
70''$call
72''$call
74''$call
75''$call
80''$call
82''$call
84''$call
85''$call
90''$call
98''$call
100''$call
105''$call

Bottom Controller
Side Controller
Permanent Adhesive
Static Cling


Volume Industry Pricing
2 Year Displax Factory Warranty
2 Year Displax Factory Warranty

Dualtouch
20''$call
22''$call
23''$call
24''$call
26''$call
30''$call
32''$call
40''$call
42''$call
43''$call
46''$call
47''$call
48''$call
49''$call
50''$call
52''$call
55''$call
57''$call
58''$call
60''$call
65''$call
68''$call
70''$call
72''$call
74''$call
75''$call
80''$call
82''$call
84''$call
85''$call
90''$call
98''$call
100''$call
105''$call

Bottom Controller
Side Controller
Permanent Adhesive
Static Cling


Volume Industry Pricing
2 Year Displax Factory Warranty
21 Day Production Schedule

Telematics Canada is as proud of our fair pricing as we are of our brilliant technology, but when there are more than 100 models that can be further customized, it becomes a bit of a challenge to keep the numbers current! We respect the value of your time by not wasting days of it just so you can get a ballpark quote for your project, so just give us a quick call and we will step you up to the plate. Or whatever the correct metaphor might be...

Checklist

Don't drive yourself crazy trying to figure out the best model, controller position, and whether to go with adhesive or static cling. Just contact our offices and in ten minutes we can review everything and find out what works best for the space and the budget. There...I'm feeling better already.

Order

If you are like everyone else, you will leave this part to the last possible moment. Then we will share in your stress and jump through every imaginable hoop to meet your evolving schedule. But first we will need payment by wire or Visa to have the factory build your order and prepare it for shipping.

Ship

We will ship your order by FedEx air to arrive within a few days after it leaves the factory. Customs are typically a modest issue, but an external variable outside of our control. Allow time for unexpected delays, and sure to provide your company's Business Number such as an EIN to expedite clearance.

Install

Your installation will typically call upon the services of a qualified film tint installer at a local glass shop. The procedure for laminating the Displax to low-iron glass is covered in this video. Be certain to specify that the installation uses distilled water and the yellow Johnson's Baby Shampoo.

Service

Displax provides their full technical expertise to assist Telematics with any issues where we have requested their assistance. Most problems are quickly diagnosed and resolved using remote access support from the factory technicians, or a simple exchange of emails and phone calls.

Warranty

Displax supports their Skin products with a comprehensive 2-year factory warranty for normal use from date of invoice of the product. During the warranty period, Displax will repair or replace defective parts that are returned by the customer to the Displax head office in Braga, Portugal.

About · Displax

In all fighting, the direct method may be used for joining battle, but indirect methods will be needed in order to secure victory. ~ Sun Tzu
Displax · Manufacturing Center
Displax is a hardware manufacturer expert in Projected Capacitive multitouch technology for Large Format Displays, typically from 30'' to 100''.

Displax develops, manufactures and markets multitouch products & technology. The main product is Skin Multitouch, a transparent foil that can be applied to non-conductive surfaces and turn them multitouch.

Based on that technology, other products are also produced including Oqtopus, a state-of-the-art multitouch table with a stunning design and Pad, an all-in-one multitouch display with a totally flat surface and sleek design.

Displax manufacturing facilities are located in the head-quarter, together with the rest of the company, to ensure an agile and continuous flow of feedback with the R&D and Sales teams.

The Skin Multitouch sensor and controller are designed in-house, by the R&D team. Displax Production team manufactures, assembles and handles all testing prior to shipping. The best equipment for the production process are used and the team has the best expertise and skills to ensure high levels of product quality.

The factory production process was designed to scale with the market growth forecasts. This ensures that Displax is able to quickly answer to changes in demand and increase the production capacity.
Displax · Manufacturing Center
Displax was born in 2000.

Initially, the main focus were contents developed on a project-by-project basis. Displax soon realized the potential of contents for new ways of human-computer interaction that were emerging from labs. To leverage this opportunity, Displax started a partnership with Minho University to anticipate the upcoming changes in the market landscape.

In 2004, Displax launched the first interactive product, Displax Interactive Window, a transparent touch technology to be applied in shop windows. Other products followed as well as projects.

Displax started to develop a network of international partners to promote and distribute its products locally using the internal skills in design, software and hardware. As time went by, Displax skills expanded, in hardware, software and electronics as well as knowledge about the market.

Around 2008 Displax began researching a way to detect simultaneous touch points using a projected capacitive sensor, as it started to be clear that multitouch would be a trend and that ProCap would be the most suited technology for different scenarios and uses.
Displax · Manufacturing Center
In 2010, at Integrated Systems Europe, Displax unveiled the prototype of a multitouch foil, what would later be launched as Displax Skin Multitouch.

For the first time a flexible ProCap multitouch technology was developed. As anticipated, the market received the news with high esteem and enthusiasm.

WIRED - "If Displax can do this for larger displays, it will really be one of the first companies to do what we call massive multitouch."

Time Tech - "We’re inching closer and closer to Minority Report status and Displax could be the company to put us over the edge."

In 2011, Displax started shipping Skin Multitouch, with 6 and 12 finger touches, Windows 7 driver and sizes from 30'' up to 100''. One year after, thousands of units were being used all around the world in cutting-edge interactive and innovative projects.

Since 2012, the Skin Multitouch is available in versions of 2, 10 and 20 finger touches and supports Windows 8, 7, Ubuntu (Linux), TUIO Protocol, Mac OS and Raspbbery Pi.
Displax · Manufacturing Center
Displax Skin Multitouch, Patent Pending PCT/IB2010/054397 and others, is the first large format through glass multitouch. Displax technology features:

XTR-Shield™, a unique proprietary noise filtering technology that allows the sensor to be closer than ever to the display, ahead of traditional sensors. As a consequence, the gap between the sensor and display is minimal and parallax is no longer an issue.

XTR-Pressure™ adds a third dimension to touch. In addition to coordinates X and Y, Displax offers a third value, for different levels of touch pressure. Developers can take advantage of this feature and create incredibly innovative new contents.

Improved touch detection algorithms, firmware and drivers are a result of the continued efforts of Displax in R&D.
